FES2000G / FES4000G

HIGH NEGATIVE PRESSURE SERIES

High negative pressure dust filtration and recovery equipment

  • OUTPUT VOLTAGE

    FILTER MATERIAL

    FILTRATION AREA

    INHALABLE DIAMETER

    DUST COLLECTION BOX

    NOISE

    POWER

    MAX NEGATIVE PRESSURE

    AIR FLOW

    NUMBER OF FILTER ELEMENTS

    FILTRATION EFFCIENCY

    EXHAUST DIAMETER

    DIMENIONS

  • FES2000G

    AC380V / 50Hz

    Polyester Fiber
    With PTFE Coating

    18m2

    55mm

    18L

    72 ± 2dB

    2200W

    >2000pa

    265m3/h

    1

    0.3μm , 99.97%

    50mm

    L600*W600*H1520 mm

    FES4000G

    AC380V / 50Hz

    Polyester Fiber
    With PTFE Coating

    18m2

    55mm

    18L

    72 ± 2dB

    4000W

    >2250pa

    389m3/h

    1

    0.3μm , 99.97%

    50mm

    L600*W600*H1520 mm

APPLICATION SCENE
Wood grinding to remove dust

Wood grinding to remove dust

Industrial grinding to remove dust removal

Industrial grinding to remove dust removal

Precious metal processing dust recovery

Precious metal processing dust recovery

Engraving dust treatment

Engraving dust treatment

Stone processing dust

Stone processing dust

Jewel processing

Jewel processing

Medical beauty industry dust

Medical beauty industry dust

Flour processing dust removal

Flour processing dust removal

  • Product Overview
  • in high-precision machining, fine grinding, and micro-particle processing applications, traditional dust collection equipment often struggles to meet the demands for high negative pressure, strong suction efficiency, and long-term stable operation. In response to these market needs, this series of low-power high negative pressure dust collectors has become an ideal choice for dust control across various industries, providing businesses with a more efficient, intelligent, and energy-saving dust filtration and recovery solution through its powerful suction force, compact design, low energy consumption, and reliable performance.
  • The core advantage of this product series lies in its design philosophy of “high negative pressure, compact size, and high efficiency.” Equipped with advanced high negative pressure suction technology, the system rapidly draws dust, fumes, and fine particles into the collector through a powerful vacuum system for highly efficient filtration. Compared with traditional dust collectors, it offers stronger suction performance and is especially suitable for collecting fine dust, lightweight particles, and suspended contaminants generated during high-precision operations. This effectively prevents dust diffusion and secondary pollution while significantly improving workplace air quality.
  • At the same time, this dust collector series adopts a low-power design. While maintaining strong negative pressure and powerful suction performance, it greatly reduces energy consumption during operation. Businesses can achieve continuous and stable dust removal performance without incurring high electricity costs, truly helping customers achieve both energy savings and environmentally friendly production goals. Its high cost-per- formance ratio has also earned widespread market recognition, making it the preferred dust collection solution for many industrial enterprises, precision manufacturing companies, and high-end production industries.
  • In terms of structural design, this high negative pressure industrial dust collector series features a compact and space-saving body structure. With a small footprint and convenient mobility, it can flexibly adapt to various production environments. Whether in precision workshops with limited space or in work areas that require frequent equipment movement, the system can be easily deployed and quickly put into operation. Its excellent mobility not only improves operational efficiency but also helps companies save valuable production space and enhance workshop layout flexibility.
  • In addition, the equipment is powered by a high-quality turbine vacuum pump as its core power system, delivering strong and stable suction performance. It is capable of 24-hour continuous operation without frequent maintenance. The mature and reliable core technology enables the equipment to maintain high-efficiency performance even under long-term heavy-duty working conditions, significantly reducing equipment failure rates and maintenance costs while providing dependable support for continuous production. Compared with many similar dust collectors on the market, this series demonstrates superior stability, durability, and overall perfor- mance, achieving the perfect balance of “high efficiency, low energy consumption, and low noise.”
  • Noise control is another outstanding feature of this product series. By optimizing the airflow structure and power system, operational noise is significantly reduced. Even during long periods of operation, the equipment maintains a low noise level, providing operators with a more comfortable working environment. This low-noise design is especially suitable for industries with high environmental requirements, such as medical aesthetics, jewelry processing, and precision instrument manufacturing.
  • In terms of applications, this series of low-power high negative pressure dust collectors offers exceptional versatility and professionalism. In industrial processing industries, the system efficiently captures and filters large amounts of fine dust generated during grinding, engraving, polishing, and similar processes, effectively reducing the impact of airborne dust on equipment and product quality. In the jewelry processing industry, fine metal particles and precious metal powders not only affect the working environment but also possess high recycling value. This equipment not only efficiently collects dust but also enables dust recovery and reuse, helping companies reduce material loss and improve economic benefits.
  • In the new energy sector, this equipment series also plays an important role. Especially in lithium battery welding production lines, smoke and fine particles generated during production can affect both product quality and equipment operation. This high negative pressure industrial dust collector can rapidly and efficiently collect welding fumes and dust, ensuring a clean and stable production environment while providing reliable dust con- trol support for new energy enterprises.
  • Furthermore, in the laser cutting industry, this series also offers dual functions of cutting support and vacuum adsorption. It not only efficiently collects dust and fumes generated during processing but also assists in ma- terial fixation and adsorption, improving processing stability and production efficiency. In automated tube-cutting line applications, the equipment also performs exceptionally well, continuously providing stable high nega- tive pressure suction support to ensure efficient production line operation.
  • Over the years, this high negative pressure industrial dust collector series has earned widespread recognition and praise from customers thanks to its mature and reliable technology, outstanding product quality, and excellent market reputation. Whether in industrial manufacturing, precision processing, jewelry manufacturing, medical aesthetics, new energy industries, or automation equipment applications, this product series demon- strates strong market competitiveness and broad application value.
  • Looking ahead, as industrial intelligence and green manufacturing continue to develop, enterprises will place even higher demands on environmental protection equipment. This series of low-power high negative pressure dust collectors will continue to focus on “high efficiency, premium quality, and excellent cost performance,” while insisting on technological innovation and product upgrades to provide customers with more professional, stable, and energy-saving dust control solutions. Choosing this product series means not only selecting a high-performance industrial dust collector but also embracing a cleaner, more efficient, and environmentally friendly future for production—making high-quality dust control a true driving force for enhancing business competitiveness.
  • Product Features
  • Small in size, it occupies little operating space, can be flexibly placed, presents a neat and aesthetic appearance, and is easy to move
  • The body adopts a fully metal integrated frame structure, which is highly impact-resistant and durable
  • High-performance brushless fan, featuring large air volume, high negative pressure, stable operation, and low failure rate
  • By manually adjusting the knob, the motor can achieve stepless speed regulation to increase or decrease negative pressure and air volume
  • Aluminum alloy impeller, with stable performance, good balance, large air volume, and low noise
  • The bottom is equipped with a dust collection box, which facilitates the collection of large particles and extends the lifespan of the main filter
  • The filter adopts a modular structure, making replacement simple and quick, with low operating costs
  • It can be used immediately after being powered on, easy to get started, simple to operate, and free from the hassle of installation
